T-Motor AUZ 18x10 VTOL Propeller
T-Motor AUZ 18x10 Carbon Fiber Propeller is a high-efficiency straight propeller developed for electric fixed-wing and VTOL UAV applications. The 18-inch diameter and 10-inch pitch configuration is designed for efficient forward flight and is matched especially well with T-Motor AT-series propulsion systems.
The propeller uses a resin-based carbon-fiber composite structure with a PMI foam core. This construction combines low weight, high stiffness and strong resistance to bending and torsion. The matte-finished propeller is designed for stable operation in demanding environments and for precise response during acceleration and deceleration.
Technical specifications
Diameter: 18 in (457.2 mm)
Pitch: 10 in (254 mm)
Average propeller weight: 39 g
Recommended max RPM: 8500 RPM
Recommended max thrust: 10.4 kg
Limit RPM: 9600 RPM
Limit thrust: 13 kg
Motor shaft connection: Ø8 mm central locking
Recommended combination: T-Motor AT5220 / AT5230 / AT5330 / AT7215 + AUZ 18x10
The AUZ series is intended for efficient cruise operation in fixed-wing and VTOL aircraft, with aerodynamic profiles optimized for electric UAV propulsion. It is suitable for applications such as surveying, logistics, inspection, agriculture, emergency response and security missions.
T-Motor AUZ 18x10 karbonski propeler je visokoučinkovit raven propeler za električna letala in VTOL brezpilotne sisteme. Premer 18 palcev in korak 10 palcev sta namenjena učinkovitemu letu naprej ter se posebej dobro ujemata z motorji T-Motor serije AT.
Propeler je izdelan iz karbonskega kompozita na osnovi smole s PMI penastim jedrom. Konstrukcija združuje nizko maso, visoko togost ter dobro odpornost proti upogibanju in torziji. Mat površina in optimizirana aerodinamična oblika sta namenjeni učinkovitemu križarjenju ter hitremu in natančnemu odzivu pogonskega sistema.
Tehnični podatki
Premer: 18 in (457,2 mm)
Korak: 10 in (254 mm)
Povprečna masa propelerja: 39 g
Priporočeni največji vrtljaji: 8500 RPM
Priporočeni največji potisk: 10,4 kg
Mejni vrtljaji: 9600 RPM
Mejni potisk: 13 kg
Pritrditev: centralno vpetje na Ø8 mm os motorja
Priporočena kombinacija: T-Motor AT5220 / AT5230 / AT5330 / AT7215 + AUZ 18x10
