Scherrer RX700NR Normal Range UHF RX

Scherrer RX700NR Normal Range UHF RX

Rx700NR is a small and very light receiver with a sensitivity of -102dBm and a optimized input filter so it can co-exist with strong 2.4Ghz on board video transmitters. The RX comes with a wire antenna mounted directly on the unit.

The RX700 NR comes with a lot of new features such as:

• External firmware upgrade port
• Running LED
• Completely new software
• Selectable PPM/PWM (S-Bus planned to come soon) upon boot.

It has also sequential fail safe, that lets you store a fail-safe pattern of 3 interactions when it hits fail safe. Through the firmware port you can access TSLRS debug tools for viewing amounts of fail-safes, blocked channels, diversity performance and much more (TSLRS USB programer needed).



Specs

• 9 servo channels

• PPM output (also called SUM signal)

• Rssi output 0.5 to 3.3V from min to mix

• Supply voltage 4-10 Volts

• Supply current RX alone 18mA at 5V

• Possible to upgrade to MCX connector

• Wideband frequency hopping system

• Uses 433 to 440 MHz ISM licence free band

• User firmware upgradeable

• Wide user temperature range -40C to +70C ambient

• Weight 8 Grams

• The receiver board is 26 x 53mm.
