Herelink 4K60 Industrial Drone FPV camera with HDMI, EIS 4.0
Professional FPV Herelink 4K60 Industrial Drone Split camera with HDMI output, EIS 4.0
| Model NO. | FIREFLY SPLIT 4K60 |
| Chipset | H22S85 + SONY IMX577(12MP） |
| Max tf card | 512GB |
| HDMI OUTPUT | YES |
| Supported HDMI resolutions | 4K30FPS/1080P60FPS/1080P30FPS/1080P24FPS/1080I60FPS/720P60FPS/720P30FPS/720P24FPS |
| USB port | USB Type C |
| Lens Diameter | 17.5MM |
| Video format | .mp4 |
| Supported video resolutions and frame rates | 4K(3840×2160) 60fps;2.7K 60fps 2.5K 60fps;1080P 120fps,1080P 60fps SuperView，720P 240fpsect |
| Image format | .jpg |
| WiFi distance | 10m |
| Support GPS | YES (Requires additional board and customized firmware) |
| Support WLAN port function | YES (Requires additional board and customized firmware) |
| 6-axis Gyro 4.0 video stabalization | YES |
| Aerial photography | YES |
| Bluetooth 4.2 Remote control | YES (Requires additional board and customized firmware) |
Herelink compatible :
1) You have to use at least 7V power
2) Choose camera resolution 1080/30 or 720/30 with TV OUTPUT- NTSC.
3) Choose HDMIT TV OUT resolution 1080/30 or 720/30
4) Turn on camera and 5 seconds later Herelink unit for no syncing issues.
DATA SHEETS:
